TECHNICAL DATA

- dimmensions: 46 mm x 25 mm x 5 mm
- RX wires [OUT]: Futaba / JR female, 22AWG, 200mm
- battery wires: [BAT1/2]: 18 AWG, 200 mm
- works with: LiPo, Li-Ion, LiFe, NiMh, NiCd

- input voltage: 5.0V – 30.0V, max 2 x 10A
- weight 20 gram (0.7 oz)
- RX plugs max 7A (3,5 A on each)
- voltage drop ab. 0.4 V
- batteries 4,8V are NOT SUITABLE
(4 cell NiMh/NiCd)
